Prototype PCB manufacturing turns a released layout into boards for engineering evaluation. For a useful first build, define what the prototype must prove, keep fabrication and assembly files at the same revision, and agree which checks belong to the bare board and which belong to the assembled circuit.

Choose bare-board prototypes or an assembled engineering build

A bare PCB order helps you inspect fabrication and assemble or evaluate the design yourself. A turnkey prototype combines board fabrication, component sourcing and assembly under an agreed release package. Neither route automatically proves firmware behavior, product compliance or every operating condition.

On a small screen, swipe the table horizontally. Keyboard users can focus the table region and use the arrow keys.

Make the prototype answer a specific engineering question

Write down the purpose of this build: checking an enclosure fit, validating a power stage, evaluating an RF path or preparing a customer demonstration. These are different acceptance tasks. A board can pass its bare-board electrical check while still requiring assembly, programming and product-level validation.

1. Freeze the design revision and name the files consistently.
2. List known risks, critical dimensions and bring-up access such as connectors or test points.
3. Provide full component MPNs and identify substitutions that require your approval.
4. Agree first-article feedback, programming and any functional procedure before assembly.
5. Record what changed after evaluation and release a controlled revision for the next batch.

Every bare PCB receives flying-probe electrical testing

OrinewPCB flying-probe tests every bare PCB we manufacture, not just a sample. This checks the conductive networks against the electrical test data. Include your netlist where available and identify any required test parameters or records in the RFQ.

An electrical pass does not establish every physical characteristic, controlled impedance, RF performance, thermal reliability or finished-product function. Specify those requirements and any additional evidence separately. This keeps the acceptance scope clear before fabrication begins.

From bare boards to genuine-component turnkey PCBA

Keep the fabrication, BOM purchasing and assembly review connected when you need a finished assembly. Small-to-medium batches and high-mix turnkey PCB assembly are a particular OrinewPCB strength. List quantities and differences for each design or variant so the release is unambiguous.

We supply and use 100% brand-new, original, genuine electronic components for customers’ turnkey assemblies. Our cooperation with manufacturers and distributors helps us seek competitive BOM pricing and practical lead times. Exact MPNs, current availability, permitted sources and delivery dates are checked for your project; alternatives require customer approval.

Explore one-stop PCB assembly, electronic component sourcing and the OrinewPCB brand website.

Nine PCBA quality stages with an agreed test scope

When the order includes assembly, our quality workflow covers nine stages. The applicable inspection plan and evidence are agreed for the actual build:

1. IQC: incoming materials.
2. SPI: solder paste inspection.
3. Online AOI: in-line optical inspection.
4. SMI: first-article inspection.
5. IPQC: in-process quality checks.
6. Offline AOI: post-solder optical inspection.
7. X-ray: hidden joints to the agreed scope.
8. Manual QC: workmanship review.
9. Pre-shipment QA: identification, quantity and packaging.

These are nine quality stages, not nine functional tests. Programming, ICT, functional testing or application-specific validation need an agreed procedure, access or fixtures, and pass/fail criteria. See our factory and quality workflow.

Plan delivery from the complete release package

We work toward the earliest practical delivery for the approved scope. Send the required quantity, design variants and target date, and state whether it means production completion, dispatch or arrival. Materials, engineering questions, assembly preparation and agreed tests all affect the confirmed schedule.

Compare quotations using the same material, revision, sourcing responsibility and acceptance scope. A lower bare-board or placement line item is not automatically a lower complete project cost.
